| 브랜드 이름: | Mckee Charging |
| 모델 번호: | CLF-FDC 65KWMH |
| 모크: | 1 |
| 가격: | Negotiate |
| 포장에 대한 세부 사항: | 나무로 되는 케이스 포장 |
| 지불 조건: | 서부 동맹, T/T, D/P, D/A, L/C |
| Parameter | Specification |
|---|---|
| Electric Current | 250A / 600A |
| Input Voltage | 327V - 456Vac |
| Power | Complete machine (0-2400A), Single circuit (0-25A), Super-charging (0-600A) |
| Output Voltage | 50V - 1000V |
| Waterproof Level | IP54 |
| Input Frequency | 45Hz - 65Hz |
| Work Temperature | -30°C to 85°C (Derated output when temperature exceeds 50°C) |
| Power Factor | ≥ 0.99 |
| Operating Humidity | 5% - 95% (No frost condensation) |
| Peak Efficiency | ≥ 95.5% |
| Elevation | ≤ 2000M |
| Output Routes | Max 12 (Compatible with 6/8/10) |
| Safety Functions | Short circuit protection, Leakage protection, Overcurrent protection, Emergency Stop |
| Material Quality | PC Flame retardant |
| Usage Methods | RFID card / Swipe card / GPRS / RS485 / CAN / Ethernet |
| Line Length | 5M / 10M |
| Network Connection | OCPP 1.6 protocol |
| Main Unit Dimensions | 1355 * 995 * 2000 mm (L * W * H) |
| Terminal Dimensions | 325 * 450 * 1430 mm (L * W * H) |
| Packaging | Wooden Case |
